General Description The SYT288A develops a high efficiency synchronous step-down DC-DC regulator capable of delivering 8A current. The device integrates main switch and synchronous switch with very low RDS(ON) to minimize the conduction loss. The SYT288A operates over a wide input voltage range from 4V to 23V. The DC-DC regulator adopts the instant PWM architecture to achieve fast transient responses for high step down applications and high efficiency at light loads. The device provides various protection features for reliable operation. In addition, it operates at pseudo-constant frequency of 600kHz to minimize the size of inductor and capacitor.
Features
Low RDS(ON) for internal switches (top/bottom): 30/10 mΩ
Wide input voltage range: 4-23V
Instant PWM architecture to achieve fast transient responses
Internal soft-start limits the inrush current Pseudo-constant frequency: 600kHz.
8A output current capability
+/-1.5% internal reference voltage
Optional bypass input Power good indicator
Output current limit protection
Hiccup mode output short circuit protection
Output over voltage protection
Input UVLO
Over temperature protection with auto recovery
RoHS Compliant and Halogen Free
Compact package: QFN3x3-20
Applications
LCD-TV/Net-TV/3DTV
Set Top Box
Notebook
High Power AP
)
)
)
)
)
)
)
)
)
)
)
)
